| Standard Parts |
| General Specifications |
| Operating System |
Android 4.4 embedded OS |
| CPU |
MSM8916, A53, 4 core CPU, 1.2GHz |
| RAM |
RAM 2G, ROM 16G |
| USB port |
5 pin MicroUSB; support OTG (U-disk/Mouse/Keyboard/USB Ethernet cable) |
| Protection Grade |
| Industrial Protection Grade |
IP67 |
| Drop Grade |
Drop resistance from 1.2m |
| Wireless Communication |
| Bluetooth |
V4.0 |
GPS
|
Support GPS, DBS, GLONASS and professional GPS,Ublox; GPS and Beidou (alternative) |
| WIFI |
WIF Support IEEE 802.11b/g/n |
| 4G |
FDD/WCDMA/GSM
LTE_FDD B1/B3/B7 LTE_TDD B41/B40
WCDMA B1//B2/B5
GSM 900/1800/1900 |
| Physical Layer Parameter |
| Display Screen |
7 inch LCD screen, 1280x800 IPS screen, capacitive touch screen |
| LED indicator light |
Support (ordinary fl icker, Call fast fl icker, missed calls) three status bar |
| Keyboard |
Android menu, Homepage, Return, Volume, Barcode, ON/OFF, Reset |
| Camera |
2 million pixels front camera, 8 million pixels rear camera with automatic focus and lighting function |
| Headset |
3.5mm audio Interface, has mike andtelephone receiver |
| Vibration Function |
Vibrating prompt function |
| Sensor |
Supports light sensation, gyroscope, compass, gravity |
| Flashlight Functio |
Used for emergency lighting |
| Rechargeable Lithium Battery |
3.7V, 7000mAh |
| Standby |
The standby current is less than 10mA |
| Dimension |
209mm*139mm*19mm |
| Weight |
590g |
