Home > products > Clear Wet inlay

Clear Wet inlay


Size:73.5x21.2mm

Chip:AZ-9662+H3





Dimensions:

Item No. Parameter
Clear wet inlay Length 1 21.20±0.20mm
Clear wet inlay Width 2 73.50±0.20mm
Clear wet inlay Corner Radius 3 R=1.60±0.20mm
Liner Width 20 80.00±1.00mm
Core ID 21 3inch(76.20±0.50mm)
Roll OD 22 ≦330.00mm
Antenna Length 28 17.00±0.20mm
Antenna Width 29 70.00±0.20mm
Clear wet inlay Gap 30 4.20±0.30mm
Clear wet inlay Pitch 31 25.40±0.30mm
Antenna to PET (Top) 32 1.60±1.50mm
Antenna to PET (Bottom) 33 1.60±1.50mm
Antenna to PET (left) 34 1.75±1.50mm
Antenna to PET (Right) 35 1.75±1.50mm
Clear wet inlay edge to liner edge (left) 36 3.25±2.00mm
Clear wet inlay edge to liner edge (right) 37 3.25±2.00mm



Read Range:
* Fix Reader:(ThingMagic FU-M6-E, 30dBm) Up to 11.5 M, off metal
* Handheld Reader: (OP9908, R2000, 30dBm) Up to 6.0M, off metal



Electrical Characteristics:

Item Description Remarks
Manufacture / IC Alien/Higgs3
Base Material PET
Antenna Al(9μm)+PET(50μm) Etched Aluminum (9μm) + PET (50μm)
Protocol ISO/IEC 18000-6C EPC Class1 Gen2
Memory EPC 96Bits Read & Write
TID 32Bits Read Only
Unique TID 64Bits Read Only
Password 32Bits Access 32 Bits Kill Read & Write
User 512Bits Read & Write
Frequency 860~960MHz
Operating Mode Passive
IC Life 100,000 Programming cycles, 10 years data retention
ESD Voltage Immunity 2000v Human being mode(HBM)



Environmental Requirement:
Adhesive Application Temperature/Humidity:[10°C to 40°C] 20% to 80%
Operating Temperature:[-20°C to +50°C]
Environmental requirements of adhesive may vary on different materials)。
Shelf Life: From the date of manufacture, 1 year at 23±5℃ / 50%±10%RH), un-seal the vacuum bag and avoid direct sunlight exposure..
Disclaimer: Our recommendations are based on our latest knowledge and experience, we reserve all rights for final explanation
